• Max. 50mm (2”) diameter hole can be drilled. The biggest sized hole for a portable gasoline engine hammer drill.
• Compatible with SDS max retainer shanks, which are available all over the world.
• Made-in-Japan quality and durability.
• Working mode can be switched between “drilling” and “hammer-drilling.”.
• For rock/concrete drilling, chiseling, mining, stone cutting, tombstone processing, drilling holes for surveyor’s markers, etc.
• CE compliant. Full Emission Control directive compliance.
• GT-5000HD ships standard with a vibration reducing handle.

Engine

Type:Two Stroke, Forced, Air Cooled, Single Cylinder

Displacement:46.5cc, Φ43×32mm(Inner bore size×stroke)

Fuel Tank Capacity:1 liter
Fuel Mixture Ratio:25:1(gasoline:2 cycle oil)
Revolution(idling):2700 rpm ±250
Revolution(loaded):9880 rpm

Maximum Output:2.3Ps/7500 rpm
Maximum Torque:0.34kg-m/5500
Compression Rate:7.1:1
Fuel Consumption Rate:380g/Ps.h

Ignition

Type:Electronic

Spark Plug Type:NGK BPMR6A

Carburetor

Type:Diaphragm

Impact

Hammer Drill:50mm (2"), Shank: "SDSmax"

Fastening Torque Range:1700 N.m(Full Throttle:1255 ft.lbf)/950 N.m(Half Throttle:701 ft.lbf)

Free Speed:1200 rpm

Capacity

Bolt Diameter:32mm(1 1/4″)

Aplications

Accessories

• Hex Key Wrench:4mm 1pc. /5mm 1pc. / 6mm 1pc.
• Spark Plug Wrench
• Spanner:10 - 13mm 1pc.
• Side Handle:1pc.
• Stopper:1pc.
• Grease:1pc.

?Remarks: Hammer Drill Bit is not included.
