| TONE > WRENCH
> POWER > POWER WRENCH |
| |
 |
| Model |
4-50N |
6-100N |
6-150N |
8-300N |
| Max. Out (Nm) |
420 |
850 |
1200 |
2550 |
| Max. In (Nm) |
140 |
283 |
400 |
850 |
| D (mm) |
56 |
62 |
78 |
89 |
| H (mm) |
57 |
67 |
68 |
91 |
| A (mm) |
9.5 |
12.7 |
12.7 |
19.0 |
| B (mm) |
12.7 |
19.0 |
19.0 |
25.4 |
| I (mm) |
107 |
123 |
143 |
179 |
| L (mm) |
377 |
466 |
475 |
587 |
| K (mm) |
96 |
109 |
124 |
163 |
| h (mm) |
45 |
62 |
71 |
97 |
| C (mm) |
43 |
51 |
58 |
82 |
| Weight (kg) |
1.5 |
2.5 |
3.6 |
7.2 |
| Width (mm) |
425 |
505 |
505 |
625 |
| Depth (mm) |
100 |
120 |
120 |
190 |
| Height (mm) |
65 |
100 |
100 |
120 |
|
| |
The products shown above are only a small part
of series,
please contact us for
your enquiry. |
| |
| |
