OTHERS > GP > GP-339AT

PRODUCT INFORMATION

  • Short wave infrared vehicle baking equipment with 3 pcs 1000W/525mm prevent dazzling tubes from the UK.
  • The working time is 7000 hours with high heating efficiency.
  • Digital program controlled.
  • 2 heating methods: Pulse heat, Full power heat.
  • The heating time can be set from 0-60 minutes.
  • Automatic working process, while auto alarm prompt once the work is finished. 4 working models can be set according to different baking time or different paintings.
  • The lamp can operate separately.
  • Automatic distance measuring function: Adjustable maximum and minimum distance between lamps and surface of the car. Lamps will be switched off when the distance is out of range. Minimizing energy waste is resulted.
  • Automatic temperature measuring function: Adjustable temperature. Lamps will be switched off when the temperature of the car surface reaches the set up value. Minimizing energy waste is resulted.
  • Automatic alarm prompt function works when the temperature or distance are out of the set up values. It also functions when the task is finished.

TECHNICAL DATA

  • Model: GP-339AT
  • Power Supply: 1PH 220V±20V 50Hz/60Hz
  • Current: 14A
  • Power: 3 x 1000 W
  • Baking Area: 1000 x 1200 mm
  • Baking Distance: 400-600mm
  • Baking Temperature: 60-100℃
  • Primer: 3-5 min
  • The First Putty: 3-6 min
  • The Second Putty: 5-8 min
  • Coating Time: 10-15 min
  • Varnish Time: 10-15 min
  • Lamp Height: 150-2500mm
  • Distance range: 25-200cm
  • Temperature range: 0-250℃
  • Size: 1760 x 1120 x 200 mm
  • Weight: 70 kg

The products shown above are only a small part of series,
please contact us for your enquiry.
